Nd:YAG Laser Resonant Cavity Mirrors Pair: HR + OC (52%) - Ø10mm
Secure payment processed via PayPal. Purchase protection included.
For custom quotes, bank transfers or any clarification do not hesitate to contact us via email.
For custom quotes, bank transfers or any clarification do not hesitate to contact us via email.
Product Description
Set of two high-performance mirrors for Nd:YAG Laser (1064 nm) resonant cavities:
- HR (High Reflector): R > 99.5% @ 1064 nm
- OC (Output Coupler): R ~ 52% (Rear surface AR coated)
- Application: Ideal for compact Nd:YAG oscillators.
Manufactured using hard dielectric PVD coatings on optical quality substrates, ensuring high damage threshold and stability.
Technical Specifications
| Product Code | 2400N |
| Wavelength | 1064 nm |
| Diameter | 10 mm |
| HR Reflectivity | R > 99.5% |
| OC Reflectivity | 52% (with AR on S2) |
| Coating Type | Dielectric Interference (PVD) |
| Substrate | Optical Glass |
