Ti:Sapphire Laser HR Mirror @800 nm - 45° AOI - Φ60mm Mounted
Secure payment processed via PayPal. Purchase protection included.
For custom coating runs, higher LIDT requirements or unmounted optics, please contact us via email.
For custom coating runs, higher LIDT requirements or unmounted optics, please contact us via email.
.jpg)
Product Description
High-reflectivity dielectric mirror optimized for Ti:Sapphire laser systems centered at 800 nm, designed for 45° Angle of Incidence.
- HR: R > 99% @ 800 nm
- AOI: 45°
- Substrate: Fused Silica
- Coating: HfO₂ / SiO₂ dielectric multilayer
- Mount: Aluminum protective frame – Φ60 mm
Typical Applications:
• Folding mirror in Ti:Sapphire resonators
• Beam steering in femtosecond CPA systems
• Regenerative amplifier routing
• CW laboratory systems
Back surface may show cosmetic marks that do not affect optical performance.
Technical Specifications
| Central Wavelength | 800 nm |
| Angle of Incidence | 45° |
| Diameter | 60 mm (mounted) |
| Substrate | Fused Silica |
| Reflectivity | R > 99% |
| Coating Type | Hard Dielectric (HfO₂ / SiO₂) |
| Manufacturing | Electron Beam PVD |
| Origin | Manufactured in EU |
