Dielectric Beam Splitters - R/T = 50/50 (±5%)
500 – 800 nm | Dimensions: 50 × 35 mm
Secure payment processed via PayPal.
For custom dimensions or volume orders, please contact us at our new email address.
For custom dimensions or volume orders, please contact us at our new email address.
Product Description
High-quality Dielectric Beam Splitters designed with a balanced R/T = 50/50 (±5%) ratio.
Optimized for the 500 – 800 nm spectral range at an Angle of Incidence (AOI) of 45°, these splitters provide nearly equal division of reflected and transmitted beams with minimal absorption.
The total dielectric coating ensures extreme durability and high damage thresholds, making them ideal for interferometry, laser beam steering, and complex optical experiments where beam quality is paramount.
Technical Specifications
| Product Code | 1300 |
| Wavelength Range | 500 – 800 nm |
| Refl. / Transm. | 50/50 ±5% |
| Angle of Incidence | 45° |
| Coating Type | Total Dielectric (PVD) |
| Substrate Material | Borofloat (SCHOTT) |
| Dimensions | 50 × 35 mm × 1.1 mm |
