Broadband HR Dielectric Mirror
Extra-wide range: 430-800 nm | Diameter 25mm
Secure payment processed via PayPal. Purchase protection included.
For custom quotes, volume orders or bank transfers, please contact us via email.
For custom quotes, volume orders or bank transfers, please contact us via email.
Product Description
Broadband high-reflectivity dielectric mirror featuring an extra-wide reflection range covering the entire visible spectrum and part of the near-infrared (430-800 nm).
This mirror utilizes an advanced multilayer dielectric coating that provides superior reflectivity (>98% average) compared to traditional metallic mirrors, with significantly higher damage thresholds and better environmental stability.
Perfect for applications involving white light sources, multi-wavelength laser systems, or spectroscopy where maintaining high efficiency across a broad range is critical.
Technical Specifications
| Product Code | T-002 |
| Wavelength Range | 430 - 800 nm |
| Avg. Reflectivity | > 98% |
| Diameter | 25 mm |
| Substrate Material | BK7 - Schott Optical Glass |
| Coating Type | Dielectric, Multilayer |
| Manufacturing | PVD (Physical Vapor Deposition) |
